OVERVIEW
SW-8GP-2SFP is a Full Gigabit Web Smart Switch equipped
with 8 10,100,1000Mbps R.J45 adaptive ports and 2 SFP fiber ports.
It supports abundant Layer 2 management functions, 802.1Q VLAN,
IGMP Snooping, static link aggregation, QOS, storm control, etc.
It can connect multiple devices, such as IP camera, iPhone phone,
WIFI-AP, Printer, etc. It is suitable for campus, hotel and enterprise
campus grid access and aggregation in various application scenarios.
FEATURE
– Support the port PoE power-off function, you can turn off or turn on the PoE power supply function at will, and support the Watch Dog
watchdog function.
– 8 PoE ports support 802.3affat, per port up to 30W with 130W Poe budget.
– Provide 8 10/100/ 1000Mbps auto-sensing RJ45 ports, and 2 10/100/1000Mbps SFP fiber ports.
– Support IEEE 802.3i, 802.3u, 802.3ab, 802.3z,802.3x, 802.3at, 802.3af/at,802.3az.
– Support MAC address automatic learning, automatic aging and aging time setting.
– CE, ROHS, FCC, UKCA , 802.1Q VLAN
