FEATURE
– Exquisite design with precise dimension and craftsmanship.
– Intemational popular smoky-gray glass front door.
– Easily be mounted on wall, or placed on floor after installed castor or feet.
– Loading capacity: 60KG.
– Top and bottom wiring channel could be closed.
– Removable front door and side panel, easily installing and maintaining
– Surface finish: Degreased, acid cleaned, phosphoric, water cleaned,
electro-static powder coating, meet ROHS standard.
– Optional color: black/gray
– Optional accessories
MATERIALS
Galvanized Cool rolled steel
Thickness: Vertical rall: 2mm
Else in 1.2mm
Tempered smoky-gray glass with thickness of 5mm.
Electro static powder coating.
Including green-yellow ground wire size 2.5mm.
APPLICATION
Widely used in network system, educational system, broadcasting
system and telecommunication system. Suitable for placing server
computer and precision electronic equipment.
STANDARD
Comply with ANSI/EIARS-310-D, DIN41491; PART 1, IEC297-2, DIN4 1494; PART7,
GB/T3047.2-92 standard, IEC 60297, ANSI/EIA-310D-1992(Rev, EA-310-C),
IEC 60297-1. IEC 60927-2Compatible with metric ETSI and 19 inch
international standard, ROHS standard.
