FEATURE
– Supply power to HD network surveillance cameras with Cat5e (PoE)
– 2x 10/100M R.J45 ports; 1x AC input port
– AC input: 100V-240V, 50-60Hz
– Coming with the Ethernet network port and PoE output port, and the power input
port with lighting-proof function (meet the secondary lightning protection)
– Can supply power with the spare line pair(4/5 (+), 7/8 (-) method or the data line
pair 1/2(+), 3/6(-) method
– No fan, natural heat dissipation, small, quiet design, suitable for desktop or wall
OVERVIEW
PoE Injector is also called as power over Ethernet mid-span devices. Single port PoE injector, that is PoE power supply module, is the
most flexible and the hottest products among the power supply devices. There are 2x RJ45 PoE ports for these single-port PoE injectors,
one of which is the Ethernet in Port for the uplink upper switches or other upper network devices, and another is PoE Out port used as the port
for network data and power output. These single-port PoE injectors supply power with the spare line pair (4/5 (+), 7/8 (-) method or the data line
pair 1/2(+), 3/6(-) method.
These PoE injectors provide a simple, economical, high-performance and intelligent way for Ethernet PoE power supply and data
communication. It’s ideal choice for those who need the superior quality project because of its simple use, easy to install, superior performance
and cost-effective. They can supply power to HD webcam through Cat5 Ethernet cable, in order that make it more flexible for the places difficult
to connect to power supply, and provide with more efficient solutions.
