OVERVIEW
SW-FGM-16SFP-L2 is a 20 port 1000M fiber switch, with 16 1000M SFP
fiber ports(100/1000M SFP or the SFP-1000BaseT R.J45 port Optional)
and 4 1000M Combo port (100M / 1000M SFP port or 10/100/1000M R.J45
port optional) uplink.
SW-FGM-16SFP-L2 supports SFP modules hot plug, and supports to
work with other fiber switches, fiber converters and other devices with
fiber ports.It supports WEB management and SNMP management , support
super network high definition video frequency transmission ability
Streamlined network structure, support dual power supply hot backup,
applies to securty system, electric system, traffic system requirements.
FEATURE
– Support 16 100/1000M SFP (or SFP- 1000BaseT R.45 ) access and 4 Gigabit Combo port (100M/1000M SFP optional, or 10/100/1000M R.J45 port)
– Support the SFP hot plug
– Support full rate, full-duplexr x non-blocking forwarding at each port
– Support WEB ,and SNMP management (optional):VLAN,STP/RSTP, Trunk port aggregation, IGMP,port Mirroring,port isolation,broadcast control,loop
detection,QinQ,etc
– Support DHCP,PPPOE,ACL,LLDP
– Support 16K MAC learning, 12Mbit storage and forward cache space, 128G back plane bandwidth, 10KByte Large frame forwarding
– Replace the remote end fiber media converter ,streamline the network structure, reduce the total cost of network systems, reduce equipment failure.
– All optic ports, strengthen the an-interference ability
– Support the AC dual redundant power supply hot backup and DC12V/5A spare battery power
– Standard 1U rack ,internal double cooling fan,better for heat dissipation,work stable .
