FEATURE
– IEEE 802.3at, IEEE 802.3af PoE standard compliance
– Provides DC 48V power over RJ45 Ethernet cable to devices
with Ethernet port
– Supports a maximum of 40 watts output power
– Support PD detection and PD classification
– Support super large video traffic
– Auto-negotiation support on RJ-45 port
– Auto-negotiation of duplex(HDX/FDX) on RJ-45 port
– Auto MDI/MDI-X support on RJ-45 port
– Supports jumbo frame size 9K bytes
– Status LED for easy monitoring of device status
OVERVIEW
The series is a Single-Port, End-Span IEEE 802.3at High Power over Ethernet converter designed specifically to satisty the growing
demand for higher power required network equipment such as PTZ (Pan, Titt & Zoom) network cameras, PTZ speed dome, color
touch-screen VolP telephones, multi-channel (IEEE 802.1 1a / b / g / n) wireless LAN access points and other network devices that
need higher power to function normally. The High Power over Ethernet converter series is an ideal solution to delivering data and
power to network devices directly via the RJ45 Port interface without the need for installing extra power outlets and electrical cabling.
