FEATURE
– Up to 155Mbps data-rate
– 1310nm FP laser and PIN photodetector 2-40km transmission
– 1550nm DFB laser and PIN photodetector for 60-80km transmission
– Compliant with SFP MSA and SFF-8472 with duplex LC receptacle
– Digital Diagnostic Monitoring: Internal Calibration or External Calibration
– 2km transmission with 50/125um MMF
– 1km transmission with 62.5/125um MMF
– Compatible with RoHS
– +3.3V single power supply
– Operating case temperature range of 0*C to +70C (Standard)
or -40C to +85*C (Industrial)
DESCRIPTION
– Class 1 laser product EN 60825-1 standards
– Operating data rate up to 2.67Gbps
– Compliant with SFP MSA and SFF-8472
– Compliant with SDH/SONET
– Duplex LC connector
-Hot pluggable
– 3.3V Single Power Supply

APPLICATIONS
– SDH STM-1, S-1.1,L-1.1, L-1.2
– SONET OC-3 IR1, LR1, LR2
– Router/Server interface
– Other optical transmission systems
